AudioCodes Mediant MSBR Series User Manual

Reference Guide 490 Document #: LTRT-17939
Mediant MSBR
Command Description
e1 Defines the E1 slot and port.
efm Defines the EFM interface slot and port (Vlan ID is
optional).
fastEthernet Defines the FastEthernet interface slot and port.
fiber interface Defines the fibre interface (Vlan ID and second vlanID are
optional).
gpon interface Defines the GPON Interface.
l2tp id Defines the L2TP ID (0 - 99).
loopback interface id Defines the Loopback interface ID (1 - 20).
multilink interface id Defines the Multilink interface ID (0 - 255).
pppoe Defines the PPPoE interface ID (0 - 7).
pptp Defines the PPTP ID (0 - 99).
serial <slot/port> Defines the serial interface slot/port.
shdsl Defines the SHDSL interface slot/port.
t1 Defines the T1 slot and port.
tunnel gre id Defines the Tunnel GRE ID (1 - 255).
vti Defines the VTI interface (1-255).
vlanID (VLAN interface)
Defines the VLAN ID for Layer 3 interfaces available via
the LAN switch.
vlanID Defines the VLAN ID for a Layer 3 sub interface.
Default
NA
Command Mode
Privileged User
Example
This example enters a specific interface configuration for the VLAN 6 menu.
(config-data)#interface vlan 6
This example configures a bridge interface.
(config-data)#interface bvi 10
