Mediant MSBR
Command Description
insert-pad
Before running this command, the debug capture must be
started.
Inserts a PAD packet. A marked packet is shown with
black background regardless of the configured coloring
rules. Benefit: A marked packet can easily be located
later when analyzing in a large capture file.
show
Displays debug status and configured rules.
start
Starts the capture.
stop
Stops the capture and sends the capture file to the
specified target. The capture file is named:
"debug-capture-voip-<timestamp>.pcap"
target
Configures the capture storage target:
• ftp
• tftp
•
usb
user
(Only applicable if ftp is specified as the
capture storage target) Configures the name
of the FTP user.
password
(Only applicable if ftp is specified as the
capture storage target) Configures the
password of the FTP user.
Command Mode
Privileged User
Note
 To free up memory on your device, it is recommended to delete the captured files
when you no longer need them, using the following command: debug capture voip
physical clear
 Capturing to USB is applicable only to devices providing USB port interfaces.
Examples
 Starting a physical VoIP debug capture:
# debug capture voip physical eth-lan
# debug capture voip physical start
 Retrieving the latest capture (PCAP file) saved on a specified server.
# debug capture voip physical get_last_capture 10.15.7.99
 Specifying USB as the destination to which to send the PCAP file:
# debug capture voip physical target usb
