AudioCodes Mediant MSBR Series User Manual

Reference Guide 780 Document #: LTRT-17939
Mediant MSBR
Syntax
ip nat inside source list <acl-name> interface <if-name>
ip nat inside source list <acl-name> interface <if-name> pool
<pool-name>
ip nat inside source list <acl-name> interface <if-name> pool
<pool-name> port <wan-port-start> <wan-port-end>
Command Description
tcp Defines forwarding for a TCP port.
udp Defines forwarding for a UDP port.
lan-ip Defines the IP address of LAN service host.
same Sets the LAN port the same as the WAN port.
lan-port Defines the port number (1-65535) of the LAN service.
wan-ip Defines the WAN interface for this rule. Specify the IP address
or 0.0.0.0 for all WAN interfaces.
wan-port Defines the port number on WAN interface.
range
Performs port forwarding on a range of ports, rather than a
single port.
acl-name Access-list defining the LAN hosts affected by the NAT rule.
if-name WAN interface name and index, to which NAT will be
performed.
pool-name IP address pool to be used on the WAN interface.
Interface Type (ifname) Interface ID
gigabitethernet
GigabitEthernet interface slot
and port (VLAN ID is optional)
[SLOT/PORT.VLANID]
cellular Cellular interface ID 0/0
gre Tunnel GRE ID [1-255]
ipip Tunnel IPIP ID [1-255]
l2tp L2TP ID [0-99]
pppoe PPPoE interface ID [1-3]
pptp PPTP ID [0-99]
vlan Vlan ID [1-3999]
loopback Loopback ID [1-5]
bvi Bridge interface [1-255]
Default
No NAT rules are defined.
