1.11 EEROM reset
This procedure can be used to reset the EEROM to the default manufacturing settings. This can under certain
circumstances correct the printer if there is a software conflict.
1. Go to Diagnostic test > 1. Electrical System Menu > 1.11 EEROM reset, and press OK.
2. The front panel asks for confirmation. Use the Up and Down keys to select Yes, and press OK.
3. Press any key to finish the procedure.
1.12 EEROM restore
This procedure can be used to restore the EEROM to the backup settings.
1. Go to Diagnostic test > 1. Electrical System Menu > 1.12 EEROM restore, and press OK.
2. The front panel asks for confirmation. Use the Up and Down keys to select Yes, and press OK.
3. Press any key to finish the procedure.
2. Substrate Path Menu
2.1 Rewinder System
Description
The purpose of this test is to visually check the Rewinder Motor operation, any failures will be displayed as a
system error, which can then be used to troubleshoot and solve the problem.
Procedure
1. Go to Diagnostic test > 2. Substrate Path Menu > 2.1 Rewinder System, and press OK to start the test.
2. The test begins and asks to unload the paper and load an empty spindle. After, press Up or Down to turn
the rewinder motor both ways. Check visually that it moves correctly in both directions.
3. When you want to finish the test, press OK to exit.
4. The front panel displays the final diagnostic result. Press OK to finish the test.
2.2 Drive Roller
Description
The purpose of this test is to diagnose a Drive Roller components failure.
You must perform the Drive Roller test after:
●
System Error Code 81:YX
●
System Error Code 41:YX
NOTE: If possible, always perform this test before replacing any Substrate Axis component.
Procedure
1. Go to Diagnostic test > 2. Substrate Path Menu > 2.2 Drive Roller.
2. The test initializes, and the front panel asks to unload the paper, and then press OK to continue.
3. The test starts to calibrate the analog encoder and shows the diagnostic results in the front panel.
Press OK to continue with the diagnostic test.
ENWW Diagnostic Menu 147
