HP Latex 300 Series

2. Disconnect the cleaning roll motor cable.
3. Remove three T-15 screws that secure the cleaning roll assembly to the Service Station chassis.
4. Remove the cleaning roll assembly.
Rewinder
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Remove the Right cover on page 246
ENWW Rewinder 337
