HP Latex 300 Series Service Manual

3. Remove two T-15 screws that secure the Spit Roller Motor plastic protector to the Service Station
chassis.
4. Remove three T-15 screws that secure the Spit Roller Motor to the Service Station chassis.
5. Remove the Spit Roller Motor.
Cleaning roll motor assembly
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Remove the Right cover on page 246.
336 Chapter 8 Removal and installation ENWW
