HP Latex 300 Series Service Manual

System error codes and warnings—explanation
System Error Codes explain which component/system is failing and what action should be taken to resolve
the problem.
System Error Codes are displayed directly on the front panel (but can also be seen on the Information Page)
and have been defined in the format XX.YZ. or XX.n:YZ.m.
●
XX: Service Part (2 digits).
●
n: Service Part Index (if more than one used in the product) – Optional.
◦
e.g. Identify the Ink Supply (color and number).
●
Y: Who should perform the action (1 digit) – (User or Service Engineer).
●
Z: Action to perform (1 digit).
●
m: additional actions/information to consider (1 digit) – Optional.
◦
e.g. Non-authorized ink was detected, PM was triggered or printhead in/out of Warranty.
The following table explains the XX part of the System Error Code or Warning:
Code Component/System
01.0 Engine PCA
01.1 PrintMech PCA
01.2 ISS Top PCA
01.3 ISS Bottom PCA
01.10 PrintMech PCA sine-wave management
01.11 PrintMech PCA sine-wave management
02.1 Carriage PCA
03 Power Supply Unit
03.10 Extra 24 V PSU
05 Formatter
05.1 Formatter Fan
05.3 Formatter Memory
06 Hard Disk Drive
08 Front Panel
09 Vacuum
11 Trailing Cable
14.3, 14.4 Heater Control Dryer Pinches
14,5, 14.6 Heater Control Dryer Overdrive
14.7, 14.8 Heater Control Curing
15 Drying System
16 Curing System
17 Other cables
21 Service Station
ENWW System error codes and warnings—explanation 67
