HP Latex 300 Series Service Manual

6. Remove the Left Cover from the printer.
Left impinging module cover
Removal
1.Open the window. See
Opening the window on page 313.
2.Remove one T-15 (Type J) screw that secures the left cover at the bottom.
3. Remove two T-20 screws from the left impinging module cover.
ENWW Left impinging module cover 251
WARNING! Heating coils operate at hazardous voltages capable of causing death or serious personal injury.
Disconnect both power cords before servicing the printer.
1.
2.
