HP Latex 300 Series Service Manual

7. Remove the cable.
8. Remove three T-10 screws that secure the right bracket to the legs of the printer.
9. Remove the bracket shown from the right side of the printer.
Take-up reel sensors
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Disconnect the Take-Up Reel Sensors, removing three T-10 screws.
ENWW Take-up reel sensors 303
