Service Maintenance Kit 2
Service Maintenance Kit #2 (part number B4H70-67104) normally includes the following parts, although the
list of parts may vary slightly:
●
Aerosol Fan Assembly
●
SVS including SVS motor, rack
●
Drop detector
●
SMK3
Clean bottom impinging surface with the provided brush.
Clean the printzone platen holes, and for the Latex 360; remove the platen, and clean the vacuum towers.
Execute all the “user” maintenance actions.
Reset the SMK2 life counter: see
3.1 Reset Maintenance Kit Usage on page 177. Perform user maintenance
procedures after the replacement: clean and lubricate the slider rod and clean the encoder strip with water
and a lint-free cloth.
Service Maintenance Kit 3
Service Maintenance Kit #3 (part number B4H70-67105) normally includes the following parts, although the
list of parts may vary slightly:
●
Line sensor
●
Pressure sensor & tube
●
Oiler + Lubricant bottle + clean and lubricate both slider rods
●
Carriage felts & Clean bushings
●
UCP (Under Carriage Protector)
●
Spit roller motor & Clean SVS PHC rods
Clean bottom impinging surface with the provided brush ensuring that the small curing air holes are free of
dried ink or any solid waste.
Clean the printzone platen holes, and for the Latex 360; remove the platen, and clean the vacuum towers.
Execute all the “user” maintenance actions.
Reset the SMK3 life counter: see
3.1 Reset Maintenance Kit Usage on page 177. Perform user maintenance
procedures after the replacement: clean and lubricate the slider rod and clean the encoder strip with water
and a lint-free cloth.
ENWW Level of printer usage 447
