HP Latex 300 Series Service Manual

5. Remove the control PCA.
6. Remove three T-20 screws to remove the Heaters Controller Enclosure.
7. The PCA isolator holder is still attached. Remove three T-10 screws, then remove the enclosure from
the PCA isolator holder. The PCA isolator is pre-pasted onto the left impinging bracket and the PCA
isolator holder. It is probably possible to replace the heater-controller enclosure without breaking the
PCA isolator.
Window trims
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Remove the Window on page 314.
2. Remove the
Right impinging module cover on page 252.
3. Remove the
Left impinging module cover on page 251.
ENWW Window trims 285
