4. Remove one T-20 screw to release the ground cable.
5. Remove the Left Rollfeed Module from the printer.
Take-up reel motor
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Raise the loading table.
296 Chapter 8 Removal and installation ENWW
