HP Latex 300 Series Service Manual

Your printer requires the following electrical components to be supplied and installed by the customer,
according to the Electrical Code requirements of the local jurisdiction of the country where the equipment is
installed.
Single-phase power
Table 1-2 Single-phase line specifications:
HP Latex 360 HP Latex 330 HP Latex 310
Printer Curing Printer Curing Printer Curing
Number of
power cords
222
Input voltage ~200-240 V +-10% (two wires and protective earth)
Input frequency 50 / 60 Hz
Maximum load
current (per
power cord)
16 A 16 A 3 A 16 A 3 A 13 A
Power
consumption per
power cord in
printing mode
2.5 kW 2.1 kW 200 W 2.4 kW 200 W 2.0 kW
Power
consumption in
ready mode
85 W 72 W 70 W
Circuit breakers
NOTE: The circuit breakers must meet the requirements of the printer and be in accordance with the
Electrical Code requirements of the local jurisdiction of the country where the equipment is installed.
The printer requires two power cords that meet the following requirements.
Table 1-3 Dedicated lines per SKU:
HP Latex 360 HP Latex 330 HP Latex 310
Printer Curing Printer Curing Printer Curing
Dedicated line Yes Yes Not required. Do
not overload
lines. See Table
2-3
Yes Not required. Do
not overload
lines. See Table
2-3
Not required. Do
not overload
lines. See Table
2-3
Branch circuit
breaker
2 poles, 16 A/20 A according to local laws and printer maximum load current
Residual current
circuit breaker
(1)
Required Recommended Recommended
2 poles, 30 mA residual, at least 20 A capacity
(1) Also known as Ground Fault Circuit Interrupter (GFCI)
