8. Remove the Primer Assembly from the Service Station.
NOTE: When installing the Primer Assembly, use the identification marks on the Primer Assembly
Tubes to ensure they are correctly connected.
Installation
1. When installing the new Primer Assembly, it is important to note that the internal tube (red) is shorter
than the external tube (green).
2. Reset “4.7.7. Primer Cycles”.
3. Perform the Calibration “5.6.2 Primer Calibration”.
Primer valves
Removal
1. Remove the
Right cover on page 246.
2. Remove the
Right connector cover on page 258.
ENWW Primer valves 343
