6. Remove the take-up reel motor from the right leg assembly.
Take-up reel left module
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Raise the loading table.
2. Remove the take-up reel spindle.
298 Chapter 8 Removal and installation ENWW
