NOTE: For HP Latex 310 Printers — Use two power cords from below
Country HP Part Number * Length Plug type Plug
U.K. 8120-6898 4.5 m BS 1363/A (13A fused)
Middle East 8120-6360 2.5 m NEMA 6-20P, 240 V, 20
A, non-locking
Table 1-6 Appliance coupler (printer connection):
Country Appliance coupler (power cable) Appliance coupler inlet (printer)
All Detachable terminal as per IEC60320-1 C19
(squared type)
Detachable inlet as per IEC60320-1 C20 (squared
type)
NOTE: Place the wall receptacle close enough to the printer so the plug can be plugged and unplugged
easily.
Electronic Cables Routing
This section can be used as a reference section, to check the original routing of the cables
18 Chapter 1 Printer systems ENWW
