7. Lift the e-box sufficiently (approximately 2 cm) to release it from the attachments.
CAUTION: Be careful not to damage the cables on top of the e-box as you remove it.
8. Remove the e-box from the printer.
Impinging pressure sensor
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Open the window. See Opening the window on page 313.
2. Remove two T-20 screws to release the pressure sensor cover.
264 Chapter 8 Removal and installation ENWW
