The upper valve has a shorter cable than the lower valve.
Primer valves cable
Removal
1. Remove the
Right cover on page 246.
2. Remove the
Right connector cover on page 258.
3. Disconnect the primer valves cable from the interconnect PCA.
4. Disconnect the Primer Assembly Cable from the Interconnect PCA.
346 Chapter 8 Removal and installation ENWW
