7. Unclip the sensor from the support bracket.
Installation
NOTE: When installing the new sensor, make sure that the rubber pipe is connected to the ‘High’ position on
the sensor.
IMPORTANT: When installing the new sensor, handle the rubber pipe with care to avoid any damage.
Damage to the rubber tube may cause inaccurate pressure readings.
Impinging recirculation cover
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Open the Window. See Opening the window on page 313.
2. Remove the Right impinging module cover on page 252.
3. Remove the
Left impinging module cover on page 251.
266 Chapter 8 Removal and installation ENWW
