HP Latex 300 Series Service Manual

4. Remove the Impinging pressure sensor on page 264.
5. Remove one T-20 screw on the left side of the Impinging Recirculation Cover.
NOTE: Hard to access with all cables. It is not required to remove the cable cover and disconnect the
cables, but it reduces the risk of damaging them.
6. Remove one T-20 screw on the right side of the Impinging Recirculation Cover.
7. Remove seven T-20 screws from the top of the Impinging Recirculation Cover.
ENWW Impinging recirculation cover 267
