HP Latex 300 Series Service Manual

Color sensor assembly
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Open the Window.
2. Remove the
Right cover on page 246.
3. Press the two sides of the Carriage PCA Cover and unclip from the Carriage Assembly.
4. Release the clip and disconnect the Color Sensor cable from the Carriage PCA.
ENWW Color sensor assembly 307
