HP Latex 300 Series Service Manual

6. If you need to remove the plastic frame holding the fan to the scan beam, loosen the screw, turn the
frame 10 degrees and pull it away.
NOTE: When installing a fan, make sure the fan is installed with its label face down.
Scan-axis motor
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Remove the Right cover on page 246.
2. Remove the
Left cover on page 249.
3. Remove the
E-box extension on page 260.
ENWW Scan-axis motor 319
