Installation
1. When installing the T-10 screw to the front of the Color Sensor, make sure you do not over-tighten the
screw.
2. When installing the T-10 screw to the rear of the Color Sensor, make sure you do not over-tighten the
screw.
Color sensor actuator assembly
Removal
WARNING! Turn off the printer and disconnect both power cords.
1. Remove the Left cover on page 249.
310 Chapter 8 Removal and installation ENWW
