HP Latex 300 Series Service Manual

8. Remove one T-10 screw from the front of the Color Sensor.
9. Remove one T-10 screw from the Rear of the Color Sensor.
10. Tilt the Color Sensor so it can be removed.
11. Remove the Color Sensor from the Carriage Assembly.
NOTE: After installing the NEW Color Sensor, perform the following Service Calibrations:
●
“5.6.3 Open Close SOL”.
●
Perform the safety test “3.3 Substrate Path Sensor”.
●
Reset the life counter “4.6.5 Color sensor”.
ENWW Color sensor assembly 309
