HP Latex 300 Series

6. Remove one T-15 screw (Type J) that secures the right cover.
7. Remove one T-15 screw (Type J) that secures the right cover.
8. Remove one T-15 screw (Type J) and one T-20 screw (Type A) that secure the right cover from the rear
of the printer.
248 Chapter 8 Removal and installation ENWW
