HP Latex 300 Series Service Manual

17. Remove four T-20 screws (Type N) that secure the right scan-axis bracket.
NOTE: Note that these are chassis screws and in normal circumstances should never be removed, but
in this case we need to remove them in order to remove the carriage assembly.
18. Remove the right scan-axis bracket from the printer.
19. Remove the Carriage Stopper Screw (T-20) from the Chassis.
374 Chapter 8 Removal and installation ENWW
