HP Latex 300 Series

5. Remove the lock receptor assembly from the vacuum beam.
6. Repeat step 4 for the lock receptor assembly on the other side of the printer.
7. Remove four T-10 screws (Type C) that secure the central removable print-zone retainer to the vacuum
beam.
398 Chapter 8 Removal and installation ENWW
