200.02—Paper Jam error service check
Step Questions / actions Yes No
1 Open the left access door. Check the input
flag (A) for damage.
Is the input flag damaged?
Replace the input sensor.
See “Sensor (input, S1,
narrow media, near
narrow media) removal”
on page 4-138.
Go to step 2.
2
Remove the staging deflector assembly. See
“Staging deflector assembly removal” on
page 4-140.
Is the input sensor (A) in the staging
deflector assembly loose?
Reseat the sensor and add
a sensor retainer. See
“Sensor (input, S1,
narrow media, near
narrow media) removal”
on page 4-138.
Contact your next level of
support.
