Waste toner left cover removal
See “Top, right, and front covers” on page 7-3 for the part number.
1. Remove the standard media tray. See “Standard media tray removal” on page 4-150.
2. Remove the logo panel. See “Logo panel removal” on page 4-85.
3. Remove the yellow print cartridge.
4. Remove the eight screws (A) from the waste toner left cover.
A (88A0323)
(88A0323) A
