Lexmark C792 series - CPU Cooling Fan Removal

To Next Page

To Previous Page

Repair information 4-49

5062

Go Back

CPU cooling fan removal

See “Rear” on page 7-15 for the part number.

1. Open the system board shield door, and remove the two screws (A) on the system board shield.

A (27S2839)
