Diagnostics menu
To run the printer diagnostic tests described in this chapter, enter Diagnostics mode.
1. Turn off the printer.
2. Press and hold 3 and 6.
3. Turn on the printer.
4. Hold the buttons until the splash screen appears.
Diagnostics menus
Dual Diode Adjust See “DUAL DIODE ADJUST” on page 3-9.
Black
Cyan
Magenta
Yellow
Diode Alignment Page
REGISTRATION See “REGISTRATION” on page 3-10.
Top Margin
Bottom Margin
Left Margin
Right Margin
Quick Test See “Quick Test” on page 3-10.
Alignment Menu See “Alignment Menu” on page 3-11.
Cyan
Yellow
Magenta
Factory Scanner
Factory Manual
Drift Sensors See “Drift Sensors” on page 3-12.
MISC TESTS
Toggle ITU See “Toggle ITU” on page 3-13.
Printhead Inst See “Printhead Inst” on page 3-13.
Auto Detect See “Auto Detect” on page 3-13.
PRINT TESTS See “PRINT TESTS” on page 3-13.
Tray 1
Tray 2 (if installed)
Tray 3 (if installed)
Tray 4 (if installed)
Tray 5 (if installed)

Lexmark C792 series Specifications

General

Print Technology	Color Laser
Print Speed (Letter, Black)	50 ppm
Print Speed (Letter, Color)	50 ppm
Processor Speed	1.2 GHz
Monthly Duty Cycle	150, 000 pages
Maximum Paper Size	8.5 x 14 inches (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Connectivity	USB, Ethernet
Media Sizes Supported	A4, A5, Letter, Legal, Executive, Folio, JIS B5
Media Types Supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Input Capacity (Standard)	650 sheets
Output Capacity (Standard)	500 sheets
