4-112 Service Manual

5062

Go Back

OP panel button removal

See “Top, right, and front covers” on page 7-3 for the part number.

1. Remove the OP panel UICC card. See “OP panel UICC card removal” on page 4-114.

2. Remove the button you want by squeezing in the latches (A) and pushing the button through the front of

the operator panel.
