200.32—Paper Jam error service check
Step Questions / actions Yes No
1 Open the left access door. Check the near
narrow media sensor flag (D) for damage.
Is the near narrow media flag damaged?
Replace the near narrow
media sensor. See
“Sensor (input, S1,
narrow media, near
narrow media) removal”
on page 4-138.
Go to step 2.
2
Remove the staging deflector assembly. See
“Staging deflector assembly removal” on
page 4-140.
Is the near narrow media sensor (D) in the
staging deflector assembly loose?
Reseat the sensor and add
a sensor retainer. See
“Sensor (input, S1,
narrow media, near
narrow media) removal”
on page 4-138.
Contact your next level of
support.
