Repair information 4-27

5062

Go Back

System board shield door removal

To remove the system board shield door, remove the rear upper cover. See “Rear upper cover removal” on

page 4-22.

System board shield removal

See “Left and rear covers” on page 7-5 for the part number.

1. Open the system board shield door, and remove the two screws (A) on the system board shield.

A (27S2839)
