ESD bracket removal
See “Top, right, and front covers” on page 7-3 for the part number.
1. Remove the operator panel assembly. See “Operator panel (OP) assembly removal” on page 4-110.
2. Remove the screw (A) securing the ESD bracket to the top cover.
A (88A0232)
