4-224 Service Manual

5062

Go Back

2000-sheet high-capacity feeder pick roll assembly removal

See“Optional 2000-sheet high-capacity feeder” on page 7-23 for the part number.

1. Remove the media tray assembly. See “2000-sheet high-capacity feeder media tray assembly

removal” on page 4-215.

2. Open the jam clearance cover.

3. Push down the pick arm until it clicks.
