Other touch-screen icons

Icon Function

Exit Exits from the current screen to the home screen

Unselected radio

button

Indicates that an item is not selected

Selected radio button Indicates a selection

Index Displays information about the key functions of the printer, including

instructions on how to operate it

Search Lets you search for files and menus

Warning

Indicates a warning or error condition
