Input option not detected (550-sheet/2000-sheet input option) service check
Step Questions / actions Yes No
1 Check the autoconnect connector for any
damage.
Is the autoconnect connector not
damaged?
Go step 3. For 550-sheet input option:
Replace the drawer
assembly. See “550-sheet
drawer assembly
removal” on page 4-166.
For 2000-sheet input
option: Replace the lift
drive motor assembly. See
“2000-sheet high-
capacity feeder lift drive
motor assembly
removal” on page 4-212.
2
Be sure that Power In (PWR IN), PPORT
(engine), and PPORT (Next option)
connectors are connected properly on the
controller card.
Are the connectors connected properly?
Go to step 4. Properly connect the
connectors.
3
For 550-sheet input option: Replace the
controller card assembly. See “550-sheet
tray controller card assembly removal” on
page 4-167.
For 2000-sheet input option: Replace the
controller card assembly. See “2000-sheet
high-capacity feeder controller card
assembly removal” on page 4-185.
Does the problem persists?
For 550-sheet input option:
Replace the drawer
assembly. See “550-sheet
drawer assembly
removal” on page 4-166.
For 2000-sheet input
option: Replace the drawer
assembly.
Problem solved.
