Lexmark C792 series - Logo Panel Removal

To Next Page

To Previous Page

Repair information 4-85

5062

Go Back

c. Remove the E-clip (I) and post (J) from the other end to remove the piston.

Logo panel removal

See “Top, right, and front covers” on page 7-3 for the part number.

1. Open the front access door.

2. Remove the three screws (A).

CI (1126827)

A (88A0323)
