3. Rotate the panel up and pull to remove it.
Low-voltage power supply (LVPS) removal
See “Rear” on page 7-15 for the part number.
1. Remove the rear cover. See “Rear cover removal” on page 4-20.
2. Push the release (A) to disconnect the power cable (B) and the fuser cable (C).
C
B
A
A
