Lexmark C792 series - Left Access Door Assembly Removal

To Next Page

To Previous Page

Repair information 4-5

5062

Go Back

Left access door assembly removal

See “Left and rear covers” on page 7-5 for the part number.

1. Open the left access door assembly.

2. Remove the three screws (A) from the cable cover, and remove the cable cover.

A (88A0323)
