Tools required for service

Flat-blade screwdriver

#1 Phillips screwdriver, magnetic

#2 Phillips screwdriver, magnetic

#2 Phillips screwdriver, magnetic short-blade

Needlenose pliers

Diagonal side cutters

Spring hook

Feeler gauges

Analog or digital multimeter

Parallel wrap plug 1319128

Twinax/serial debug cable 1381963

Coax/serial debug cable 1381964
