7. Parts catalog
How to use this parts catalog
• Asm-index: Identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and item number 1 in the table.
• Part number: Identifies the unique number that identifies this FRU.
• Units/mach: Refers to the number of units actually used in the base machine or product.
• Units/option: Refers to the number of units in a particular option. It does not include the rest of the base
machine.
• Units/FRU: Refers to the number of units packaged together and identified by the part number.
• Description: Provides more descriptive information to help identify the part.
• Removal procedure: Links directly to the instructions for removing the part.
• NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
• Model information used in the parts catalog:
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description Removal procedure
Abbreviation
used
Machine type
and model
Printer name
210 5062-210 C792e
230 5062-230 C792de, C792dte
235 5062-235 C792dhe
239 5062-239 CS796de
