Conventions

Note: A note provides additional information.

Warning: A warning identifies something that might damage the product hardware or software.

There are several types of caution statements:

CAUTION

A caution identifies something that might cause a servicer harm.

CAUTION

This type of caution indicates there is a danger from hazardous voltage in the area of the

product where you are working. Unplug the product before you begin, or use caution if the

product must receive power in order to perform the task.

CAUTION

This type of caution indicates a hot surface.

CAUTION

This type of caution indicates a tipping hazard.
