Cartridge blower assembly removal
See “Front” on page 7-7 for the part number.
1. Remove the right cover. See “Right cover removal” on page 4-24.
2. Remove the front access door. See “Front access door assembly removal” on page 4-3.
3. Remove the screw (A) in the top cover.
A (88A0323)
