HTU output option guide removal
1. Remove the rear standard bin cover. See “HTU rear standard bin cover removal” on page 4-312.
2. Slide the cables through the rear standard bin cover.
HTU output option solenoid removal
1. Remove the rear standard bin cover. See “HTU rear standard bin cover removal” on page 4-312.
2. Disconnect the output bin solenoid cable (A).
Note: Tie a string to the cable so you can route the new cable through the HTU.
