Repair information 4-257
5062
Finisher or stacker bottom cover removal
See “Finisher/High-capacity output stacker assembly” on page 7-25 for the part number.
1. Remove the option from the printer.
2. Remove the standard output bin LED and LED lens. See “Finisher or stacker standard output bin LED
and LED lens removal” on page A-277.
3. Press the tabs on the bin media present to remove the sensor from the cover.
4. Disconnect the cable from the beacon card.
