200.42—Paper Jam error service check
Step Questions / actions Yes No
1 Open the left access door. Check the narrow
media flag (C) for damage.
Is the narrow media flag damaged?
Replace the narrow media
sensor. See “Sensor
(input, S1, narrow media,
near narrow media)
removal” on page 4-138.
Go to step 2.
2
Remove the staging deflector assembly. See
“Staging deflector assembly removal” on
page 4-140.
Is the narrow media sensor (C) in the
staging deflector assembly loose?
Reseat the sensor and add
a sensor retainer. See
“Sensor (input, S1,
narrow media, near
narrow media) removal”
on page 4-138.
Contact your next level of
support.
