4-284 Service Manual

5062

Go Back

HTU access door rollers removal

1. Remove all output options from the printer.

2. Remove the HTU access door. See “HTU access door removal” on page 4-282.

3. Remove the screw (A) from the roller you are replacing, and remove the roller.

A (3015189)
