2000-sheet high-capacity feeder pass thru sensor removal

See“Optional 2000-sheet high-capacity feeder” on page 7-23 for the part number.

1. Open the media tray assembly.

2. Open the jam clearance cover.

3. Disconnect the pass thru sensor connector (A) from the pass thru sensor.

4. Release the latch (B) securing the pass thru sensor.
